XERAFY Dot Wedge
Plug-In-Metal UHF RFID Tags


The Xerafy Dot Wedge offers outstanding performance in the most demanding temperature and pressure. Its unique design makes it able to be fully embedded in metal, delivering a read range of up to 3.3 ft(1 m)at optimal performance.

This IP68-rated RFID Tag uses a high performance polymer for the casing to ensure exceptional dirt, chemical, UV and wear resistance, as well as excellent mechanical properties built for high temperatures environments.

Features

  • High performance RFID-on metal tags
  • Passive UHF EPC Class 1 Gen 2
  • IP68 rating
  • Simple Installation
  • Embed into Metal Version

Specifications

Physical Characteristics
DimensionsØ 10.3 mm x 4.6 mm
Weight8g
Case MaterialHigh performance engineering polymer
MountingPlug-In Embedded, Optional Epoxy
Environmental Characteristics
Operating Temperature-40 to 85°C
survival Temperature
(Long Term)
-50 to 220°C
IP ClassificationIP68
Compression strength10,100 psi (70 MPa)
Chip Characteristics
IC TypeAlien Higgs 3
Operating Frequency Range902 MHz - 928 MHz
Memory Configuration64-bit TID; 96-EPC bits, extendible to 480 bits
Read RangeUpto 1.0 m
Ordering Information and Pricing
Part Number Model Number Description RRP
Inc GST
T
%
[A] XERAFY Dot Wedge UHF RFID In Metal Tag
9-9891-640-2
