AOPEN - Chromebox Commercial
Touchscreen


The Chromebase Commercial is a solid-state device designed to be extremely robust and secure, making it ideal for interactive public display in high traffic environments (i.e. as a digital signage, POS or kiosk system). For connecting other devices such as POS peripherals and authentication devices (i.e. biometrics), the Chromebase Commercial has commercial ports, ruling out the need for multiple power cables.

Chrome device management allows administrators to manage their organization’s Chrome devices from a single place. Integrators can also use the signage app of their preference available via the Chrome Web Store to control what’s on the screen.

Features

  • Dual HDMI and Display Port Support
  • Commercial grade multi-touch Chrome OS
  • Tough and tamperproof design for 24/7 operability in public spaces
  • Small form factor for easy instalment behind displays or integration in kiosks
  • Solid State fanless design ensure a first-rate performance in challenging situations
  • 3 Year Warranty
Specifications
Physical Characteristics
Width 166mm
Height 25mm
Depth 158mm
Weight 1.12 Kg
Environmental Characteristics
Operating Temperature 0 to 40°C
Storage Temperature -10 to 60°C
Operating Humidity 0 to 90% (Non-Condensing)
Storage Humidity 0 to 90% (Non-Condensing)
Electrical
Power Source External 100 ~240 V/AC, 1.5A
Power Adaptor Output +19.0 V/DC, 65W/3.4A
(12V/19V DC Connector Socket)
System Configuration
Graphics Intel HD graphics, integrated on CPU
CPU Intel N2930,1.83 GHz turbo to 2.16 GHz Quad Core
RAM Dual Channel 4GB/1333 MHz
Storage 32GB
Serial 1x RJ50 RS232
USB4 USB 2.0 Ports (2 front, 2 rear - with BC)
Network1 RJ45 Ethernet
AudioMaxim MAX98090 Combo audio Jack - Mic-in/Line-out
Wireless2x 802.11ac, Dual Band, 2x2 WiFi+Bluetooth 4.0 Antenna Ports
Operating SystemChrome OS
Ordering Information and Pricing
Part Number Model Number Description RRP
Inc GST
T
%
[A] Chromebox Commercial
AODE3255-CHROME
