... engineering ICT solutions. 		EFTPOS Plus Modular LAN Outlet    Product Home
Product information

The UMD Model P180 - EFTPOS PLUS Modular LAN Outlet is a cost effective pre-built component which enables you to interconnect your Commonwealth Bank EFTPOS PLUS multi-drop terminals without the need to contract an Austel approved electrician.

Each EFTPOS PLUS Modular LAN Outlet enables connection of two EFTPOS PLUS terminals to a shared K74 EFTPOS modem.

Upto to 16 EFTPOS Terminals can share one modem by adding EFTPOS PLUS Modular LAN Outlets connected together with Link Cables.

Features

  • Simple installation - no electrician required
  • Each EFTPOS PLUS Modular LAN Outlet connects upto 2 EFTPOS terminals
  • Upto 16 EFTPOS Plus terminals can be connected to one Modem
  • 12 months return to base warranty

Ordering Information and Pricing


Part Number Qty Model Number Description RRP T
%
Inc GST
[A] EFTPOS PLUS Modular LAN Outlet
9-6900-180-3

P180

EFTPOS LAN Terminal Box

 $99.00 10%
[B] EFTPOS Plus Modular LAN Link Cable
2-6073-010-5

CA6073-1

Modular Patch RJ45 - 1m (Blue)

 $2.57 10%
2-6073-020-1

CA6073-2

Modular Patch RJ45 - 2m (Blue)

 $3.08 10%
2-6073-030-3

CA6073-3

Modular Patch RJ45 - 3 (Blue)

 $3.59 10%
2-6073-050-1

CA6073-5

Modular Patch RJ45 - 5m (Blue)

 $5.13 10%
2-6073-100-9

CA6073-10

Modular Patch RJ45 - 10m (Blue)

 $10.27 10%
2-6073-150-4

CA6073-15

Modular Patch RJ45 - 15m (Blue)

 $15.40 10%
2-6073-200-6

CA6073-20

Modular Patch RJ45 - 20 (Blue)

 $20.53 10%
2-6073-300-3

CA6073-30

Modular Patch RJ45 - 30m (Blue)

 $25.67 10%
2-6073-400-0

CA6073-40

Modular Patch RJ45 - 40m (Blue)

 $30.80 10%
2-6073-500-7

CA6073-50

Modular Patch RJ45 - 50m (Blue)

 $35.93 10%
Custom length cables are also available. Please contact UMD Sales for quotation.
[C] Application Note and Order Form
UMD Application Note 173: UMD P180 EFTPOS PLUS Modular LAN System and Order Form can be downloaded here(in PDF format).


Document Reference: umd_p180 Issue: 2005-06-28 | Edit
