HID - Sense Iot Asset+
Indoor & Outdoor Asset Tracker


The HID Sense IoT Asset+ provides effortless indoor and outdoor asset tracking using a range of connectivity protocols with its multiyear replaceable battery. This industrial asset tracker is suitable for a range of IoT applications. Its best performance is for laydown yards, manufacturing facilities, airports and outdoor warehouses. Track industrial assets such as construction equipment, pipes and ground support equipment.

Multiple sensors operate together to provide instant asset tracking. The accelerometer detects a moving asset that initiates a LoRa signal. Once the asset is at rest, either Bluetooth Low Energy will activate indoor positioning or the GNSS receiver will transmit using LoRaWAN for accurate outdoor positioning. Manage individual assets with the inbuilt LED and buzzer, activated via Bluetooth Low Energy or LoRa downlink. Receive battery life and device state periodically with the configurable LoRa heartbeat payload. Each communication protocol can be configured using NFC.

Features

  • Identify individual assets with its bright LED and buzzer
  • IP68 to withstand harsh industrial environments
  • Bright LED and buzzer quickly identifies individual assets
  • Replaceable high capacity batteries
  • Connects to UMD's Chariot Broker service
  • Real time insights via Hexicore Dashboard

Specifications

Physical Characteristics
Dimensions135.3 mm × 69 mm × 33 mm
InstallationRivet Attachment, Cable Tie
MaterialOvermoulded shock resistance TPE
Environmental Characteristics
Operating Temperature-20ēC to +60ēC
Storage Temperature-20ēC to +60ēC
Ingress ProtectionIP68
Vibration & ShockMIL_STD 810H
Power
Battery2 x replaceable AA LS14500 (5.2Ah total)
Battery LifeUp to 3 years
Communications
Radio ProtocolsLoRaWAN 1.0.4, LoRa, Bluetooth Low Energy, NFC, GNSS
Beacon RateConfigurable LoRa Heartbeat
Movement start LoRa Beacon
New position LoRa Beacon
2.5 / 5 / 10 sec (Bluetooth LE)
IndicatorsBright Green LED & Buzzer


Ordering Information and Pricing
Part Number Model Number Description RRP
Inc GST
T
%
[A] HID Sense IoT Asset+ Asset Tracker
CP18079 Sense Asset with GPS, BLE, LED, Buzzer and LoRaWAN connectivity $260.70 A1
[B] Value Added Services
UMD-Chariot - IOT Device Management Platform
